DBNS-7
DBNS-7 single tube night vision goggle
Single tube night vision goggle for observation, surveillance and land navigation, hand-held or face-mask worn, compatible with all laser types.
Enlarge DBNS-7 single tube night vision goggle
Specification
| Magnification | X1 |
|---|---|
| Field of view | 40 deg |
| Focus range | 0.25 m to infinity |
| Diopter adjustment | -2 to +6 dptr |
| Exit pupil / eye relief | 10 mm / 15 mm |
| Interpupillary distance | 55 mm to 75 mm |
| Objective focal length | 26 mm |
| Input voltage | 2.2 to 3.1 VDC |
| Battery type | 2 x AA or NiCd |
| Battery life | min. 40 hours |
| Goggle weight | 570 g |
| Length/Width/Height | 150x152x77 mm |
| Operating temperature | -45 deg C to +50 deg C |
| Immersion | 1 m for 30 min |
All data provided for information purposes; final specification is defined per contract. Full technical data sheets are issued on request against a stated end-user.
