KT-EU M84
KT-EU M84 electro-percussion gun primer
An electro-percussion gun primer intended for initiating the base charge, working either on 2.1 J impact energy or through a firing circuit of 1 to 3.6 ohms resistance.
Enlarge KT-EU M84 electro-percussion gun primer
Specification
| Primer type | electro-percussion |
|---|---|
| Minimum conditions for action - impact energy (J) | 2.1 |
| Voltage and current-pulse duration | 20 V / 0.004 s |
| Electrical resistance of the circuit (Ω) | 1 ÷ 3.6 |
| Primer height (mm) | max 24 |
| Primer diameter (mm) | max Ø30 |
| Thread (mm) | SpW 27.178 x 14 pitches |
| Powder | black powder No. 7 |
| Powder mass (g) | 1.35 |
| Primer mass (g) | 85 |
| Operating temperature | -30 to +50 °C |
All data provided for information purposes; final specification is defined per contract.
