23 mm x 115, HE
23x115 mm HE
23x115 mm high-explosive round, 174 g projectile with 16.3 g explosive at 720 m/s, for GSh-23L and GSh-23LU aircraft guns.
Also written: 23 mm, 23 mm x 115, 23 x 115, 23X115, 23x115
Specification
| Projectile type | HE (high explosive) |
|---|---|
| Round mass | approx. 329 g |
| Projectile mass | 174 +/- 3.5 g |
| Explosive mass | 16.3 g |
| Propellant mass | 37 g |
| Round length | 197.9 to 200.53 mm |
| Muzzle velocity | 720 +/- 10 m/s |
| Mean max pressure (group of rounds) | 3000 bar |
| Fuze arming distance | 100 m |
| Operating temperature | -30 to +50 deg C |
| Weapon compatibility | 23 mm aircraft guns GSh-23L and GSh-23LU |
| Packing | 100 rounds in a tin box, box in a nailed case with tow handle, 30 cases per pallet |
All data provided for information purposes; final specification is defined per contract. Full technical data sheets are issued on request against a stated end-user.
