UT, M68P1
UT M68P1 mortar impact fuze
Superquick impact mortar fuze with interrupted explosive train and removable transport safety element, permanently screwed to the shell.
Show UT M68P1 mortar impact fuze, view 1 of 2Show UT M68P1 mortar impact fuze, sectioned
Enlarge UT M68P1 mortar impact fuzeEnlarge UT M68P1 mortar impact fuze, sectioned
Specification
| Fuze type | Impact fuze, superquick action |
|---|---|
| Safety design | Interrupted explosive train; percussion-detonator (duplex) primer out of axis with firing pin when unarmed |
| Transport safety | Transport safety element must be removed before firing; protects the shell during handling, transport and parachuting |
| Arming | Inertia force as the shell passes out of the mortar powder chamber; arming ring and arming balls release the primer holder |
| Muzzle safety when fired with ignition cartridge | 8 m |
| Muzzle safety note | Increases when fired with a greater number of increment charges |
| Ammunition compatibility | Mortar shells |
All data provided for information purposes; final specification is defined per contract. Full technical data sheets are issued on request against a stated end-user.
